Set_Fly_Rot_Pos - Scanlab RTC6 PCIe Board Installation And Operation Manual

Normal List

set_fly_rot_pos

Command
Function Activates Processing-on-the-fly correction for compensation of workpiece or scan system
rotary movement (based on angular position values transferred to the RTC6 by the
McBSP
Restriction If the Option Processing-on-the-fly
Processing-on-the-fly process (even though it could not have been activated).
set_fly_rot_pos( Resolution )
Call
Parameters Resolution
• Resolution can be negative depending on the rotation direction of the workpiece. The
Comments
restricted value range applies only to the absolute value.
• For Processing-on-the-fly correction and determining the Resolution parameter, see
Chapter 8.6 "Processing-on-the-fly", page
• Before executing set_fly_rot_pos, you should define the rotation center for
Processing-on-the-fly correction by
the default value (0|0) is used.
• If unallowed parameter values are supplied (for example, for Resolution = 0), then
set_fly_rot_pos does not activate a Processing-on-the-fly correction or deactivates a
Processing-on-the-fly correction previously activated by set_fly_rot_pos (but does not
deactivate any other Processing-on-the-fly correction). The latter case leads to a jump
(at jump speed) to the endpoint of the most recently executed
"Arc" Command
• The various Processing-on-the-fly corrections cannot be arbitrarily combined, see
Section "Overview", page
• For deactivating Processing-on-the-fly correction, see
Processing-on-the-fly Correction", page
• The
applications and
See also
• The
mcbsp_init. That is, data provided is not transmitted, see
RTC4RTC6 Unchanged functionality.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
set_rot_center, set_rot_center_list, fly_return, read_mcbsp,
References
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
interface). It thereby sets the corresponding Resolution parameter.
Number of steps per revolution.
As a 64-bit IEEE floating point value.
Allowed value range: |Resolution| > 100.0.
(without "set_fly_rot_pos" Processing-on-the-fly correction).
242.
McBSP interface cannot be simultaneously used for both Processing-on-the-fly
Online Positioning.
Section "Notes", page
McBSP interface ignores the first FrameSync signal after a
is not enabled, then set_fly_rot_pos terminates the
242.
set_rot_center or set_rot_center_list. Otherwise,
Chapter 8.6.5 "Deactivating
251.
230.
Vector Command or
load_program_file or
page 86.
set_fly_rot
651
