Normal List timed_mark_abs_3d
Command
Function Moves the laser focus for the specified marking duration along a 3D vector from the
current position to the specified position (absolute coordinate values) within the
3D Image
Restriction If the Option "3D"
select_cor_table), then timed_mark_abs_3d has the same effect as timed_mark_abs.
However, split-up into
the effective mark speed in the xy plane.
timed_mark_abs_3d( X, Y, Z, T )
Call
X
Parameters
Y
Z
T
Comments • Except for the additional motion in the third dimension, timed_mark_abs_3d
functions similarly to
• See also comments on mark_abs_3d.
RTC4RTC6 New command.
See mark_abs_3d.
RTC5RTC6 Unchanged functionality. In addition: increased value range.
Version info Available as of DLL 600, OUT 600, RBF 600.
References timed_mark_abs, mark_abs_3d,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Field.
is not enabled or no 3D correction table has been assigned (see
Microsteps is calculated like a 3D command and hence influences
Like mark_abs_3d.
Like mark_abs_3d.
Like mark_abs_3d.
Duration of the complete mark vector. In µs.
As a 64-bit IEEE floating point value.
Allowed value range: [0...167,772,160]. The parameter is rounded to an
integer-multiple of 10. Out-of-range values are clipped.
If T < 5, then timed_mark_abs_3d behaves like mark_abs_3d.
timed_mark_abs
timed_mark_rel_3d
(see the comments there).
