2.7.3 Solder Jumper Field C –
Configuring Pin (15) of
EXTENSION 2 Socket Connector
The solder jumper field C is located on the lower side
of the RTC6 PCIe Board, see
It serves to configure the signal at pin (15) of the
EXTENSION 2 socket connector, see the following
table.
See also "Configuration by Solder Jumpers", page
Allowed
jumper setting
Pin17 Pin15
open
Data7 Data7
open
+5V +5V
open
GND GND
Latch
Pin17 Pin15
open
Data7 Data7
open
+5V +5V
closed*
GND GND
Latch
Pin17 Pin15
open
Data7 Data7
closed*
+5V +5V
open
GND GND
Latch
Pin17 Pin15
closed*
Data7 Data7
open
+5V +5V
open
GND GND
Latch
*
Caution: make sure that only one position is closed
in this solder jumper field. Other combinations are
not allowed and cause damage to the board!
(a) Synonym: Data Bit #7. MSB
RTC6 boards
Doc. Rev. 1.0.21 en-US
2 Product Overview
Figure 6.
80.
Output at the
EXTENSION 2
socket connector
pin (15)
No signal.
GROUND
(low level).
+5 V
(high level).
(a)
DATA 7 .
of the 8-bit output value.
Notes
• Configurations of solder jumper field C and
solder jumper field B are independent from each
other.
• On RTC6 Ethernet Boards, the printed label of
solder jumper field B is 'Pin15'. This has been
chosen deliberately in order to keep consistency
with already existing RTC boards. Even though
with RTC6 Ethernet Boards pin (08) of the EXT. 2
socket connector, see
Socket Connector", page
configured.
Chapter 16.2.12 "EXT. 2
891, is actually
43
