Undelayed

list_jump_cond

Short List
Command
Conditional absolute list jump: list_jump_cond executes list_jump_pos(
Function
current IOvalue at the EXTENSION 1 socket connector's 16-bit digital input port meets the
following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0). Otherwise, the
directly following list command is immediately executed.
list_jump_cond( Mask1, Mask0, Pos )
Call
Mask1
Parameters
Mask0
Pos
Comments • list_jump_cond is synonymous with
RTC4RTC6 Basically unchanged functionality. However:
• Jumps into or out from the protected
(illegal
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References list_jump_pos,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
16-bit mask.
As an unsigned 32-bit value.
Only the lower 16 bits are evaluated.
See Mask1.
Absolute jump address [0...(2
As an unsigned 32-bit value.
Jump Commands are ignored during processing, see also list_jump_pos).
list_jump_pos_cond
23
–1)].
list_jump_pos_cond (see comments there).
RTC6 List Memory area "List 3" are not allowed
Pos
), if the
482
