2.8.4 Slot Cover with 9-pin D-SUB
Connector for "2. SCANHEAD"
Socket Connector
For connecting a second scan head or a z axis to the
2. SCANHEAD Socket Connector
available, see
Figure
2:
• #115132
Its 9-pin D-SUB connector has the same pin-out as the
SCANHEAD
Connector, see
See also
Section "Second Scan Head Slot Cover
(Accessory)", page
68.
1
2
Legend
1. 9-pin D-SUB connector (female).
pin-out as
Figure
10.
2. l = 225 mm.
3. To
2. SCANHEAD Socket
Second Scan Head Slot Cover (Accessory)
RTC6 boards
Doc. Rev. 1.0.21 en-US
2 Product Overview
a slot cover is
Figure
10.
3
1
Connector.
2
#115132.
2.8.5 Slot Cover with 15-pin D-SUB
Connector for
"MARKING ON THE FLY"
Socket Connector
For using the input ports and signals of the
MARKING ON THE FLY Socket
is available, see
Figure
3:
• 109272
The pin-out of its 15-pin D-SUB connector (female) is
shown in
Figure
26.
See also
Section "MARKING ON THE FLY Slot Cover
(Accessory)", page
83.
2
1
3
1
Legend
1. 15-pin D-SUB connector (female).
pin-out as
Figure
26.
2. l = 105 mm.
3. To
MARKING ON THE FLY Socket
MARKING ON THE FLY Slot Cover (Accessory)
Connector, a slot cover
Connector.
3
109272.
