jump_rel

Command
Function
Moves the output point (of the laser focus) along a 2D vector at jump speed from the
current position to the specified position (relative coordinate values) within a 2D
Field.
Call
jump_rel( dX, dY )
Parameters
dX
dY
Comments
• The coordinates for the jump vector end point are to be supplied as relative
coordinates with respect to the current position. Otherwise, jump_rel is identical to
jump_abs
RTC4RTC6
Unchanged functionality. In addition: increased value range.
In
RTC4 Compatibility
The allowed value range decreases accordingly.
RTC5RTC6
Unchanged functionality. In addition: increased value range.
Version info
Available as of DLL 600, OUT 600, RBF 600.
References
jump_abs, jump_rel_3d,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Relative x coordinate of the jump vector end point. In bits.
As a signed 32-bit value.
Allowed value range: [–268,435,456...+268,435,455].
Out-of-range values are clipped to the boundary values.
The complete value range is only usable as a virtual
for (enabled) Processing-on-the-fly applications.
Like dX (analogously).
(see comments there).
Mode, the RTC6 multiplies the specified values for dX and dY by 16.
timed_jump_rel
Field, for example,
468
