Normal List timed_mark_rel
Command
Function Moves the laser focus for the specified marking duration along a 2D vector from the
current position to the specified position (relative coordinate values) within a 2D
Field.
Call timed_mark_rel( dX, dY, T )
Parameters dX
dY
T
Comments • The coordinates for the mark vector end point are to be supplied as relative coordinates
with respect to the current position. Otherwise, timed_mark_rel is analogous to
timed_mark_abs
RTC4RTC6 Unchanged functionality. In addition: increased value range.
See mark_rel.
RTC5RTC6 Unchanged functionality. In addition: increased value range.
Version info Available as of DLL 600, OUT 600, RBF 600.
References timed_mark_abs, mark_rel,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Like mark_rel.
Like mark_rel.
Duration of the complete mark vector. In µs.
As a 64-bit IEEE floating point value.
Allowed value range: [0...167,772,160]. The parameter is rounded to an
integer-multiple of 10. Out-of-range values are clipped.
If T < 5, then timed_mark_rel behaves like mark_rel).
(see the comments there).
timed_mark_rel_3d
