micro_vector_abs_3d

Command
Function Moves the output point (of the laser focus) by a
Microsteps) directly from the current position to the specified position (absolute
coordinate values) within the
Restriction If the Option "3D"
select_cor_table), then micro_vector_abs_3d has the same effect as micro_vector_abs.
micro_vector_abs_3d( X, Y, Z, LasOn, LasOff )
Call
Parameters X
Y
Z
LasOn
LasOff
Comments • Except for the additional motion in the third dimension, micro_vector_abs_3d
functions similarly to
RTC4RTC6 New command.
In RTC4 Compatibility
those for LasOn and LasOff by 64. The allowed value ranges decrease accordingly.
RTC5RTC6 Unchanged functionality.
In RTC5 Compatibility
LasOn and LasOff by 32. The allowed value ranges decrease accordingly.
Version info Available as of DLL 600, OUT 600, RBF 600.
References micro_vector_abs,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
3D Image
is not enabled or no 3D correction table has been assigned (see
Absolute x coordinate of the micro vector end point. In bits.
As a signed 32-bit value.
Allowed value range: [–268,435,456...+268,435,455].
Out-of-range values are clipped to the boundary values.
The complete value range is only usable as a virtual
for (enabled) Processing-on-the-fly applications.
Like X (analogously).
Like X (analogously), except
Allowed value range: [–524,288...+524,287].
LaserOn Delay. 1 bit equals 1/64 µs.
As a signed 32-bit value.
Allowed value range: [–1...+(2
 0:
Delay is newly set. Values over (2
< 0: The previously set delay continues unaffected.
LaserOff Delay.
Like LasOn.
micro_vector_abs
Mode, the RTC6 multiplies the specified values for X, Y and Z by 16,
Mode, the RTC6 multiplies the specified value for Z by 16, those for
micro_vector_rel_3d
"Hard Jump" (without split-up into
Field.
Image Field
15
–1)].
15
–1) are clipped.
(see comments there).
for example,
