8.7.4 Synchronization

The pixel output timing diagram for one image line
with 3 pixels is shown in
Figure
To prepare the laser control,
set_pixel_line/set_pixel_line_3d
Signals for "Laser Active" Operation
Mark Command
after a
LaserOff Delay
Jump
Command) and waits until the laser is actually
off.
During this waiting period, the
galvanometer scanners do not move in
Mode"
(Mode = 0, see
page
modes, they continue to move at the speed defined
by HalfPeriod and pixel distance in equidistant
Microsteps. This allows to program jerk-free run-in
and run-out movements. Initial acceleration phases
can be hidden by a
LaserOn Delay
[*]mark[*]
Command) or by a corresponding number
of "idle pixels" (see below).
After that, depending on the laser mode, pixel
output starts immediately or after a Q-Switch delay,
see
Figure
66. Analog signals at
ANALOG OUT2
change synchronously with the
leading edge of each pixel pulse. The digital-to-
analog converter requires about 1.5 µs...3 µs to
produce a stable analog output signal. With pixel
output frequencies above around 100 kHz
(HalfPeriod < approx. 320) digital-to-analog
conversion cannot always be fully completed. At such
pixel output frequencies, it must be carefully checked
whether the functionality is sufficient for the
intended purpose.
in set_laser_control(
Bit #1
shift the laser pulse and thus the start of the digital-
to-analog conversion by half a pixel period.
The pixel line ends with the first list command that is
not a
set_pixel
or set_n_pixel.
For the laser to be switched off even in the middle of
a 10 µs cycle, a default pixel is automatically
outputted after the last pixel. This is repeated as
often as necessary until a started 10 µs cycle is
finished. Then the laser is finally switched off.
RTC6 boards
Doc. Rev. 1.0.21 en-US
8 Advanced Functions for Scan Head Control and Laser Control
66.
switches off the
from a previous
(as with a
"Classic
712) only. In all other
(as with a normal
ANALOG OUT1
or
Ctrl
) can be used to
The default pixel should be defined appropriately
prior to
set_pixel_line/set_pixel_line_3d
achieve a non-visible laser marking (= "idle pixels") in
the run out, see
set_port_default
set_default_pixel.
The RTC6 board waits – especially at pixel output
frequencies < 100 kHz – until the default pixel is
outputted.
The galvanometer scanners continue to run during
this time, to ensure jerk-free connection movements
(programmed by the user). No scanner delay is
automatically inserted. In
"Classic Mode"
see
page
712), the galvanometer scanners remain
idle for a few clock cycles. With Mode + 256 this can
be suppressed (even for the forerun phase).
The
Tracking Error
and the hidden acceleration phase
mean a pixel line shift", see
needs to be compensated for by an adjusted run-in.
To make this easier, Mode + 512 can be used to
switch on
Sky Writing Mode
the run-in and run-out phase and thus place the pixel
line with pinpoint accuracy, see
Phase
Run-in
Nprev
Nprev
Swing-out
movement
Modus + 512
These movements cannot be combined with
Sky Writing Mode
2. The duration of the swing-out
movement must be explicitly defined via
set_sky_writing_para
in advance.
(1) With excelliSCAN scan heads
automatic delay calculation need to be switched on,
see
"excelliSCAN Scan Heads – Functional Principle of
SCANahead Servo Control and Operation by RTC6
Boards"
Manual.
in order to
and
(Mode = 0,
Figure
66. Normally, this
1-similar movements in
Figure
65.
Phase
Pixel
line
Run-out
t
Post
movement
65
Nprev
of
(1)
,
Sky Writing
and
268
