Ctrl Command uart_config
Function Configures the internal UART interface for the specified baud rate.
RealBaudRate = uart_config( BaudRate )
Call
BaudRate
Parameters
RealBaudRate
Result
Comments • uart_config extends
• uart_config is synonymous with rs232_config, but returns the nearest possible
actually used baud rate.
• The default value is 9,600 baud.
• The other RS-232 interface parameters cannot be altered (data bits: 8, start bits: 1, stop
bits: 1, parity: none).
• See also
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 611, OUT 611, RBF 616.
References rs232_config, rs232_write_data,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Baud rate. As an unsigned 32-bit value.
Allowed value range: [160 Bd...12.8 MBd].
rs232_config
Chapter 4.6.5 "RS232 Socket Connector", page
rs232_read_data
with a higher value range for the baud rate.
83.
