Ctrl Command set_scanahead_params
Function Only for scan systems with SCANahead technology, for example, the excelliSCAN.
Activates the SCANahead functionality suitable to control an SCANahead system on the
RTC6 board. The laser control and digital inputs/outputs for the peripherals are prepared
for a SCANahead system, that is, delayed by PreviewTime.
To have also the Scanner Delays and Laser Delays calculated automatically,
activate_scanahead_autodelays
Restriction set_scanahead_params can only be executed, if no list is currently active.
Otherwise,
set_scanahead_params can only be executed, if the
Otherwise,
returned.
Error = set_scanahead_params( Mode, HeadNo, TableNo, PreviewTime, Vmax, Amax )
Call
Parameters Mode
HeadNo
TableNo
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
must be called.
get_last_error return code gets set to
get_last_error return code gets set to
= 0: Deactivates the RTC6-SCANahead functionality. The additional
parameters TableNo, PreviewTime, Vmax, Amax are not taken into
account. Default after load_program_file.
Mode, for example, for operating intelliSCAN scan heads.
= 1: Queries parameters of the scan head with the specified HeadNo and
applies them. The parameters PreviewTime, Vmax, Amax are not taken
into account. See also comments that follow.
Mode for operating attached SCANahead systems.
= 2: Uses the parameters of set_scanahead_params.
Mode, for example, for software development. A SCANahead system
does not need to be connected.
As an unsigned 32-bit value.
Number of the scan head connector.
Allowed values:
= 1: Scan head connector 1.
= 2: Scan head connector 2.
Option "Second Scan Head Control"
As an unsigned 32-bit value.
Allowed value range: 1...8. A correction file should have been loaded by
load_correction_file(
and Vmax from control bits (galvanometer scanner rotation angle) into
programing bits (Image Field
As an unsigned 32-bit value.
RTC6_BUSY
and error code 5 is returned.
Option "SCANa"
RTC6_REJECTED
required.
No ). This is used for converting the parameters Amax
coordinates). See get_scanahead_params.
is enabled.
and error code 1 is
