Undelayed

set_vector_control

Short List
Command
Function Initializes or deactivates "vector-controlled laser control". See
Laser Control", page
Call set_vector_control( Ctrl, Value )
Parameters Ctrl
Value
Comments • If Ctrl is an invalid value, then "vector-controlled laser control" is deactivated
(Ctrl = 0, initialization state). Otherwise, Value is applied as the starting value of the
next
value.
• set_vector_control only affects
• If an "Automatic Laser Control" has been activated by
same control parameter
of the "Automatic Laser Control" to value Value.
However, this does not apply to Ctrl = 5: set_auto_laser_control(
("Spot Distance
set_vector_control
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
206.
Control parameter for initializing or deactivating "vector-controlled laser
control" (for Ctrl = 1...6: identical with set_auto_laser_control).
As an unsigned 32-bit value.
= 1...8: Defines which signal parameter is to be varied by "vector-controlled
laser control".
= 1: 12-bit output value at the
= 2: 12-bit output value at the
= 3: Output value at the 8-bit digital output port.
= 4: Pulse length (PulseLength) of the
LASER1 and LASER2.
= 5: Output period (HalfPeriod) of the
LASER1 and LASER2.
= 6: Output value at the 16-bit digital output.
= 7: Focus shift ("Defocus").
= 8: Reserved for intelliWELD.
= 0 or > 8: deactivates "vector-controlled laser control".
Defines the starting value for the parameter selected by Ctrl.
As an unsigned 32-bit value.
Allowed values (out-of-range values are clipped to the boundary values):
For Ctrl = 1/2:
For Ctrl = 3:
For Ctrl = 4:
For Ctrl = 5:
For Ctrl = 6:
For Ctrl = 7:
Command. If Value is invalid, then it is clipped to the maximum allowed
[*]para[*]
= 1...6), then set_vector_control sets the 100% value
(Ctrl
Control") and "vector-controlled laser control" with
(Ctrl = 5) (HalfPeriod) cannot be combined.
ANALOG OUT1
ANALOG OUT2
Laser Control Signals
Laser Control Signals
12-bit values [0...4095].
8-bit values [0...255].
32
[0...(2 –1)]. 1 bit equals 1/64 µs.
32
[0...(2 –1)]. 1 bit equals 1/64 µs.
16-bit values [0...65,535].
[–524,288...+524,287],
Value = focus shift + 524,288.
[*]para[*] Commands.
set_auto_laser_control
Section "Vector-Defined
output port.
output port.
with the
Ctrl
= 7 )
