Set_Rtc4_Mode - Scanlab RTC6 PCIe Board Installation And Operation Manual

Ctrl Command set_rtc4_mode
Function Sets RTC4 Compatibility Mode

set_rtc4_mode()

Call
Comments • RTC4 Compatibility Mode
made available so that user programs written for the RTC4 can also be processed by
the RTC6 (to a large extent) without needing to modify the programming code.
However, a prerequisite here is that the program can only contain RTC4 commands
that also exist with unchanged functionality as RTC6 commands. In the command
descriptions of this user manual such changes are noted in the "RTC4RTC6" row.
• RTC6 Standard Mode
also be specified subsequently by set_rtc6_mode.
• The current
• set_rtc4_mode is available even without explicit access rights to a particular board.
• set_rtc4_mode is not available as a multi-board command.
• The scope of set_rtc4_mode is not board-specific, but rather global to the
and all RTC6 boards to which the user program has access rights.
• The board-specific error variables
Handling", page
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References get_rtc_mode, set_rtc5_mode,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
as the current
is an optional operation mode of the
is predefined as the default
RTC6 DLL operation mode can be queried by get_rtc_mode.
LastError
130) are neither generated nor altered by set_rtc4_mode.
set_rtc6_mode
RTC6 DLL operation mode.
RTC6
RTC6 DLL operation mode and can
AccError
and (see Chapter 6.8 "Error
DLL. It has been
RTC6 DLL
721
