Ctrl Command set_start_list_pos
Function Opens the
the specified relative position in the specified list ("List 1" or "List 2").
set_start_list_pos( ListNo, Pos )
Call
ListNo
Parameters
Pos
Comments • The next list command is stored at the specified address and all further list commands
at the subsequent addresses in the selected list.
• The specified list is unconditionally opened for loading. There is no checking of
whether the list is currently being processed, see also
page 105
• The input pointer cannot be set to the protected
protected area is to be written to (at the full risk of users) with set_start_list_pos, then
this area can be temporarily allocated to "List 2" by config_list( Mem1, –1 ) .
After writing, configuration of the area's protection should be restored:
config_list( Mem1,
• For uneven ListNo values, "List 1" is opened, otherwise "List 2". This facilitates
continuous automatic list changing though incrementing counts.
• If "List 2" has not been assigned memory
opened.
• If Pos is specified as being larger than the memory area of the respective list (Pos >
or Pos > Mem2), then Pos is set to 0.
• The status values of the selected list (see also read_status) are set as follows:
LOAD list status
of the other corresponding list is reset.
• set_start_list_pos triggers a flush of the buffered list input, see
"Loading Lists", page
• set_start_list_pos also covers the specialized variants set_start_list_1,
set_start_list_2,
• Caution! If the end of the respective
input pointer is automatically reset to the start of the same
Make sure not to overwrite any commands still needed by your user program.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References execute_list_pos,
