Mark_Abs - Scanlab RTC6 PCIe Board Installation And Operation Manual

Normal List

mark_abs

Command
Function Moves the laser focus at mark speed along a 2D vector from the current position to the
specified position (absolute coordinate values) within a 2D
mark_abs( X, Y )
Call
X
Parameters
Y
Comments • If the mark speed has not been previously explicitly set by
set_mark_speed_ctrl, then the marking is executed at a predefined mark speed of
1,000 bits/ms.
• The
of the marking (or remain on after a directly preceding
"Arc"
account, see
Control", page
Exception: zero-length
RTC4RTC6 Unchanged functionality. In addition: increased value range.
In RTC4 Compatibility
The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality. In addition: increased value range.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_mark_speed, set_scanner_delays, mark_rel, arc_abs,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Absolute x coordinate of the mark vector end point. In bits.
As a signed 32-bit value.
Allowed value range: [–268,435,456...+268,435,455].
Out-of-range values are clipped to the boundary values.
The complete value range is only usable as a virtual
for (enabled) Processing-on-the-fly applications.
Like X (analogously).
Signals for "Laser Active" Operation
Command). The defined
Chapter 7.2 "Delay Settings – Coordinating Scan Head Control and Laser
145. Note that other delays are executed in
[*]mark[*]
Mode, the RTC6 multiplies the values specified for X and Y by 16.
are automatically turned on at the beginning
[*]mark[*] Command
Scanner Delays and Laser Delays
Commands, see Section "Notes", page
timed_mark_abs
Field.
Image Field for example,
set_mark_speed or
or
are thereby taken into
Sky Writing mode.
149.
524
