Scanlab RTC6 PCIe Board Installation And Operation Manual page 929

17 Appendix B: The UFPM Extension Board
The UFPM Extension Board
(2)
RTC6 PCIe Boards .
The assembly is shown in
details in Figure 91.
(1) For example, #137980, #140965, #152803.
(2) Cannot be uses with RTC6 Ethernet Boards for
mechanical reasons.
MARKING ON THE FLY
LASER
SCANHEAD
UFPM Extension Board: Assembly with the
Note: The Second Scan Head Slot Cover (Accessory)
RTC6 boards
Doc. Rev. 1.0.21 en-US
17 Appendix B: The UFPM Extension Board
(1)
has been developed for
Figure 90, dimensions and
RTC6
SCANLAB
V1.2
RTC6 PCIe Board
(#115132) cannot be used.
The UFPM Extension Board converts 8-bit digital
signals into analog voltage values using a fast digital-
to-analog converter.
It is recommended, if:
• Analog controlled lasers are operated and
• Pixel output frequencies  100 kHz
achieved (see set_pixel_line)
(3) Option "UFPM" is mandatory for pixel output
frequencies 800 kHz...3,2 MHz.
(4) The UFPM Extension Board also supports pixel output
frequencies < 100 kHz, of course.
EXTENSION 1
.
(3)(4)
are to be
EXTENSION 2
1 2
STEPPER MOTOR
RS232
McBSP/ANALOG
90
