Undelayed sub_call_abs
Short List
Command
Function Causes an unconditional jump to an indexed subroutine. In the called subroutine, any
absolute
current coordinates at the time of the call).
sub_call_abs( Index )
Call
Index
Parameters
Comments • sub_call_abs reads the indexed subroutine's starting address from the internal
management table based on the supplied index and then calls
the comments there).
• If the called subroutine contains no absolute commands, then there is no difference
between sub_call_abs and sub_call.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References sub_call,
Undelayed sub_call_abs_cond
Short List
Command
Function Conditional call (AbsCall) of an indexed subroutine: sub_call_abs_cond executes
sub_call_abs( Index ), if the current IOvalue at the 16-bit digital input port of the
EXTENSION 1 socket connector meets the following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0). Otherwise, the
directly following list command is immediately executed.
sub_call_abs_cond( Mask1, Mask0, Index )
Call
Mask1
Parameters
Mask0
Index
Comments • See sub_call_abs.
• See also
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
sub_call_abs
References
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Vector Commands and "Arc"
Index of the called indexed subroutine.
As an unsigned 32-bit value.
Allowed value range: [0...1023].
list_call_abs
sub_call_abs_cond
16-bit mask.
As an unsigned 32-bit value.
Only the lower 16 bits are evaluated.
See Mask1.
Index of the called indexed subroutine.
As an unsigned 32-bit value.
Allowed value range: [0...1023].
Chapter 9.3.2 "Conditional Command Execution", page
Commands receive an offset (corresponding to the
then triggers the jump to the subroutine.
list_call_abs (see also
295.
