Ctrl Command stepper_rel_no
Function Triggers a set-position movement to the specified relative position at one stepper motor
output port.
stepper_rel_no( No, dPos, WaitTime )
Call
No
Parameters
dPos
WaitTime
Comments • The set positions should be specified relative to the current position values (the -
position value is correspondingly get newly set) and a set-position movement is only
performed at the stepper motor output specified by No. Otherwise, stepper_rel_no is
identical to
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References stepper_abs_no, stepper_abs,
Undelayed stepper_rel_no_list
Short List
Command
Function Like stepper_rel_no, but a list command and without
Call stepper_rel_no_list( No, dPos )
Parameters No
dPos
Comments • See stepper_rel_no.
• During performance of a reference run (see stepper_init), execution of
stepper_rel_no_list is delayed until the reference run completes.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References stepper_rel_no
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Like stepper_abs_no.
Relative position. In CLOCK pulse units.
As a signed 32-bit value.
31
Allowed value range: [–2
Like stepper_abs_no.
stepper_abs (see comments there).
stepper_rel_no_list
Number of the stepper motor output port.
As an unsigned 32-bit value.
Allowed values:
= 1: Stepper motor output port 1.
= 2: Stepper motor output port 2.
If the value is invalid, then stepper_rel_no_list is, already during loading,
replaced by a list_nop (get_last_error
Like stepper_rel_no.
31
...+(2 –1)].
WaitTime parameter.
return code RTC6_PARAM_ERROR).
