mark_rel_3d

Command
Function Moves the laser focus at mark speed along a 3D vector from the current position
to the specified position (relative coordinate values) in the
Restriction If the Option "3D"
select_cor_table), then mark_rel_3d has the same effect as mark_rel. However, split-up
into Microsteps
mark speed in the xy plane.
mark_rel_3d( dX, dY, dZ )
Call
dX
Parameters
dY
dZ
Comments • The coordinates for the mark vector end point are to be supplied as relative coordinates
with respect to the current position. Otherwise, mark_rel_3d is identical to
mark_abs_3d
RTC4RTC6 Unchanged functionality. In addition: increased value range.
In RTC4 Compatibility
16. The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality. In addition: increased value range.
In RTC5 Compatibility
The allowed value range decreases accordingly.
Version info Available as of DLL 600, OUT 600, RBF 600.
References mark_abs_3d, mark_abs, mark_rel,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
is not enabled or no 3D correction table has been assigned (see
is calculated like a 3D command and hence influences the effective
Relative x coordinate of the mark vector end point. In bits.
As a signed 32-bit value.
Allowed value range: [–268,435,456...+268,435,455].
Out-of-range values are clipped to the boundary values.
The complete value range is only usable as a virtual
for (enabled) Processing-on-the-fly applications.
Like dX (analogously).
Like dX (analogously), except
Allowed value range: [–524,288...+524,287].
(see comments there).
Mode, the RTC6 multiplies the values specified for dX, dY and dZ by
Mode, the RTC6 multiplies the value specified for dZ by 16.
timed_mark_rel_3d
3D Image Field.
Image Field for example,
