Set_N_Pixel - Scanlab RTC6 PCIe Board Installation And Operation Manual

Variable

set_n_pixel

List Command
Function In Pixel Output
command Number times in immediate succession.
set_n_pixel( PortOutValue1, PortOutValue2, Number )
Call
PortOutValue1
Parameters
PortOutValue2
Number
Comments • For usage of set_n_pixel, see
• Before the first set_n_pixel command of a line,
• set_n_pixel defines the parameters for the following Number (identical)
commands of an image line. For usage, see comments on set_pixel.
• If only an individual pixel is to be defined, then
to set_n_pixel.
• Outside
set_pixel
Under some circumstances, a
Short, Variable and Multiple List Commands", page
RTC4RTC6 New command.
For RTC4 Compatibility
RTC5RTC6 Unchanged functionality.
See set_pixel.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_pixel, set_pixel_line,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Mode, executes PortOutValue1 and PortOutValue2 assigned to the
Like set_pixel.
Like set_pixel.
Number of pixels.
As an unsigned 32-bit value.
Allowed value range: [1...(2
Chapter 8.7 "Pixel Output Mode", page
is synonymous with set_n_pixel ( Number = 1 ).
set_pixel
Pixel Output Mode (if set_n_pixel is not directly preceded by set_pixel_line,
or set_n_pixel), set_n_pixel is a short list command and otherwise ignored.
list_continue
Mode: see set_pixel.
set_pixel_line_3d
32
–1)]. 0 is automatically set to 1.
set_pixel_line must have been called.
set_pixel can be used as an alternative
might be inserted, see Section "Normal,
302.
set_pixel
263.
set_pixel
705
