Undelayed

if_pin_cond

Short List
Command
Function Conditional command execution:
if_pin_cond immediately executes the directly following list command, if the current
IOvalue at the
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0).
Otherwise, this list command is skipped.
if_pin_cond( Mask1, Mask0 )
Call
Mask1
Parameters
Mask0
Comments • See also
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
if_not_pin_cond, if_cond,
References
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
LASER Connector's 2-bit digital input port meets the following condition:
2-bit mask.
As an unsigned 32-bit value.
Only the lower 2 bits are evaluated.
See Mask1.
Chapter 9.3.2 "Conditional Command Execution", page
if_not_cond
295.
462
