Undelayed

if_fly_y_overflow

Short List
Command
Function
Conditional command execution for Processing-on-the-fly applications:
if_fly_y_overflow immediately executes the directly subsequent list command, if the
condition in accordance with Mode for the y axis has been fulfilled.
Otherwise, this list command is skipped.
if_fly_y_overflow( Mode )
Call
Mode
Parameters
Comments
• For usage of if_fly_y_overflow, see
page
• The error bits queried in accordance with Mode (error bit
are reset.
RTC4RTC6
New command.
RTC5RTC6
Unchanged functionality.
Version info
Available as of DLL 600, OUT 600, RBF 600.
References
get_marking_info, set_fly_limits, clear_fly_overflow, clear_fly_overflow_ctrl,
if_not_fly_y_overflow
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
To-be-evaluated condition.
As a signed 32-bit value.
= 0:
Some kind of boundary exceedance occurred
(error bit
Bit #6
> 0:
An overflow occurred (error bit
< 0:
An underflow occurred (error bit
256.
= 1 or error bit
Bit #7
= 1).
Bit #7
= 1).
Bit #6
= 1).
Section "Customer-Defined Monitoring Area",
Bit #6
and/or error bit
Bit
#7)
455
