Para_Jump_Rel_3D - Scanlab RTC6 PCIe Board Installation And Operation Manual

Normal List

para_jump_rel_3d

Command
Function Moves the output point (of the laser focus) along a 3D vector at jump speed from the
current position to the specified position (relative coordinate values) within the
3D Image
set_vector_control
Restriction If the Option "3D"
select_cor_table), then para_jump_rel_3d has the same effect as para_jump_rel.
However, split-up into
the effective jump speed in the xy plane.
para_jump_rel_3d( dX, dY, dZ, P )
Call
dX
Parameters
dY
dZ
P
Comments • The coordinates for the jump vector end point are to be supplied as relative
coordinates with respect to the current position. Otherwise, para_jump_rel_3d is
identical to
• P is not treated on a relative basis.
RTC4RTC6 New command.
In RTC4 Compatibility
The allowed value range decreases accordingly. For the parameter P, see para_jump_abs.
RTC5RTC6 Unchanged functionality.
For the parameter P, see para_jump_abs.
Version info Available as of DLL 600, OUT 600, RBF 600.
References jump_rel_3d, set_vector_control, para_jump_abs_3d,
RTC6 boards
