10.3 Unsupported RTC4/RTC5
Commands
Some RTC4/RTC5 commands are not supported by
the RTC6. Most of them can be replaced by
RTC6 commands, see following tables.
Ctrl Command dsp_start
Support status This RTC4 command is not supported by the RTC6.
RTC4RTC6 This command is not needed for normal operation. The
program file is loaded by load_program_file.
Ctrl Command free_rtc5_dll
Support status This RTC5 command is not supported by the RTC6.
Replaced by free_rtc6_dll
Ctrl Command get_xy_pos
Support status This RTC4 command is not supported by the RTC6.
RTC4RTC6 Replaced by get_value,
Ctrl Command get_xyz_pos
Support status This RTC4 command is not supported by the RTC6.
RTC4RTC6 Replaced by get_value,
Ctrl Command init_rtc5_dll
Support status This RTC5 command is not supported by the RTC6.
Replaced by init_rtc6_dll
Ctrl Command read_pixel_ad
Support status This RTC4 command is not supported by the RTC6.
RTC4RTC6 There is no equivalent RTC6 command.
Ctrl Command rtc4_count_cards
Support status This RTC4 command is not supported by the RTC6.
Replaced by rtc6_count_cards
Ctrl Command rtc5_count_cards
Support status This RTC5 command is not supported by the RTC6.
Replaced by rtc6_count_cards
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
get_values
get_values
DSP starts automatically after the
