Scanlab RTC6 PCIe Board Installation And Operation Manual page 75

LASER1 (01)
LASERON (02)
/START (03)
BUSY OUT (04)
DIGITAL OUT2 (05)
DIGITAL IN2 (06)
+5 V (07)
ANALOG OUT1 (08)
LASER Connector, see also Figure
See also Section "Option "DC/DC Converter"", page
RTC6 boards
Doc. Rev. 1.0.21 en-US
4 RTC6 PCIe Board – Layout and Interfaces
+5V
10 SN74LVC1G126
SN74LVC1G126
+5V
10 SN74LVC1G126
+3.3V
+3.3V
4k7
74HC14
+3.3V
74HC14
+5V
SN74LVC3G34
+5V
SN74LVC3G34
74HC14
+3.3V
+3.3V
4k7
74HC14
On RTC6 boards without
"DC/DC" option
this jumper is closed.
+5V
+12V
TLE2142
17: input/output wiring.
38.
On RTC6 boards without
"DC/DC" option the signals are
not galvanically decoupled
and GND2 = GND.
+5V
10
(09) LASER2
(10) GND2
+3.3V
4k7
(11) /STOP
+5V
SN74LVC3G34
(12) DIGITAL OUT1
+3.3V
+3.3V
4k7
(13) DIGITAL IN1
(14) GND
+12V
TLE2142
(15) ANALOG OUT2
18
75
