18.3 Installation and Operation
• When installing the RTC6 Ethernet Board, a static
IP address must be obtained. For that, you have
to set the jumper field Force DHCP on the
RTC Ethernet board.
(1) Make sure that the RTC6 EtherBox is
disconnected from the power supply.
(2) Unscrew the two Torx screws on the back of
the RTC6 EtherBox and remove the housing
cover.
(3) Set the jumper field 'Force DHCP', see
Figure 95, to "Force DHCP
J0501
1
"Force DHCP position"
(4) Put the housing cover back on and screw the
two Torx screws from step 2.
(5) Connect the RTC6 Ethernet Board to the
power supply back on again and a network,
see also Chapter 16.3.3 "Connecting to a
Network", page 899.
(6) More information about installation and use
of the RTC6 Ethernet Board (inside the
RTC6 EtherBox) can be found in the main part
of the RTC6 Manual.
RTC6 boards
Doc. Rev. 1.0.21 en-US
18 Appendix C: The RTC6 EtherBox
position":
3
Force
DHCP
