Undelayed

set_fly_limits_z

Short List
Command
Function Defines the boundaries of the customer-defined monitoring range for z axis
Processing-on-the-fly applications.
Call set_fly_limits_z( Zmin, Zmax )
Parameters Zmin
Zmax
Comments • For usage of set_fly_limits_z, see also
Processing-on-the-fly Corrections", page
• During initialization (with load_program_file), the boundary limits get set to the
following default values:
– Zmin = –524,288
– Zmax = +524,287
• Boundary limits specified using the parameter value 0 also get set to the above-
mentioned default values.
RTC4RTC6 New command.
In RTC4 Compatibility
16. The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality.
In RTC5 Compatibility
16. The allowed value range decreases accordingly.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_fly_limits,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Range boundary.
As a signed 32-bit value.
Allowed value range: [–524,288...+524,287].
Out-of-range values are clipped to the boundary values.
Like Zmin (analogously).
Mode, the RTC6 multiplies the specified values for Zmin and Zmax by
Mode, the RTC6 multiplies the specified values for Zmin and Zmax by
get_marking_info
Chapter 8.6.9 "Monitoring
255.
649
