Ctrl Command auto_cal
Function
Controls the functions for (automatic self-) calibration of the scan system attached to the
specified scan head connector.
ErrorCode = auto_cal( HeadNo, Command )
Call
HeadNo
Parameters
Command
Result
Error code or type of sensor system.
As an unsigned 32-bit value.
3
6
The following error codes are only returned after Command = 0...3:
0
1, 10, 11
2, 20, 22
4, 40, 44
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Number of the scan head connector. As an unsigned 32-bit value.
Allowed values:
= 1:
First scan head connector.
= 2:
Second scan head connector.
Requires
Option "Second Scan Head
Control parameter. As an unsigned 32-bit value.
Allowed value range: [0...4].
= 0:
The RTC6 detects the current Home-In positions, stores them in the
RTC6 DLL
and in the
initializes the gain and offset values (Gain = 1.0, Offset = 0).
= 1:
The RTC6 detects the current Home-In positions,
calculates and sets the new gain and offset values and thereby
activates drift compensation.
= 2:
The RTC6 deactivates drift compensation by initializing the gain and
offset values (Gain = 1.0, Offset = 0).
= 3:
The RTC6 detects the current Home-In positions
(but – in comparison to Command = 1 – leaves the gain and offset
values unchanged and that is, does not activate drift compensation
= 4:
The RTC6 checks the ASC hardware whether a scan system
attached to the specified scan head connector is equipped
with an internal sensor system for automatic self-calibration – Home-
In sensors) and returns the type and status of the detected sensor
system. The detected type is also stored in the
auto_cal cannot be executed because the
INTERNAL-BUSY list execution status
Parameter error.
No error.
Home-In sensor not found (this could also mean a Home-In sensor is defective)
(1: for x axis (galvanometer scanner 2)
10: for y axis (galvanometer scanner 1)
11: for both axes).
The spread in measured values during a measurement cycle is too high
(2: for x axis / 20: for y axis / 22: for both axes).
Reference data not found (only for Command = 1 and 3)
(4: for x axis / 40: for y axis / 44: for both axes).
Control".
Flash Memory
as Home-In reference values and
BUSY list execution status
is currently set.
Flash
Memory.
or
332
