7.1.2 Microstepping

The RTC6 PCIe Board splits up each
• Jump Command,
• [*]mark[*] Command and
• "Arc" Command
into so-called
• Microsteps
(not: Microvectors, see
"micro_vector[*] Commands", page
The split-up of the x component of a vector into
Microsteps is shown in Figure
x
Δx
(t | x )
Δt
0 0
x x coordinate of the current output
0
position before scanning the vector.
x x coordinate of the vector end position.
1
t Output interval 10 µs.
The x component of a vector is split-up into Microsteps.
The y component is split-up in the same way.
All Microsteps are transferred to the scan head with
a constant output interval (t) of 10 µs and cannot be
changed.
The following applies:
Length s of a
Microstep
(v = current jump speed or mark speed)
(1) Alternatively see Chapter 8.9 "Timed Commands",
page 274.
RTC6 boards
Doc. Rev. 1.0.21 en-US
7 Basic Functions for Scan Head Control and Laser Control
Chapter 8.8
273).
34.
(t | x )
1 1
(t +i Δt | x +i
Δx)
× ×
0 0
t
34
(1)
= v × t
Notes
• Custom curves can be implemented by using
micro_vector[*] Commands, see
"micro_vector[*] Commands", page
• Only iDRIVE scan systems
with an appropriate tuning can execute jumps
also in Jump Mode, see
"Jump Mode", page 217.
(2) See Glossary entry on page
Chapter 8.8
273.
(2)
which are equipped
Chapter 8.1.5
27.
140
