Ctrl Command write_da_x
Function Writes an output value to one of the analog output ports of the RTC6.
write_da_x( x, Value )
Call
x
Parameters
Value
Comments • See also
• The output range of the analog output ports is 0 V...10 V.
• For x < 1 or x > 2, write_da_x is ignored
(get_last_error
• write_da_1
(without parameter x).
RTC4RTC6 Unchanged functionality.
In RTC4 Compatibility
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
write_da_x_list
References
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Number of the analog output port.
As an unsigned 32-bit value.
Allowed values: [1, 2] (1: ANALOG
12-bit output value for the selected analog output port.
As an unsigned 32-bit value.
Higher bits are ignored.
Value = 0 corresponds to an output value of 0 V.
12
Value = 2
–1 corresponds to an output value of 10 V.
Chapter 9.1.4 "12-Bit Analog Output Port 1 and 2", page
return code RTC6_PARAM_ERROR).
/ write_da_2 can be used alternatively to write_da_x
Mode, the RTC6 multiplies the specified Value by 4.
OUT1, 2: ANALOG OUT2).
283.
