Ctrl Command get_scanahead_params
• The returned parameter values are also used by set_scanahead_params.
Comments
• Vmax is the maximum angular velocity of the galvanometers.
Vmax is not the mark speed in the image plane.
For this reason, the unit is "In bits/10 µs." and not "In Bits/ms.".
Distortion by the correction file is not yet taken into account in the returned parameter
value (see set_scanahead_params).
• HeadNo = 256 only returns meaningful values if
called.
• The values returned by HeadNo = 256 are scaled. Do not use them with
set_scanahead_params(
• For dual SCANahead systems (for example, 2 excelliSCAN scan heads; requires
"Second Scan Head
used have as similar properties as possible (aperture, lens, correction file): For
automatic calculation of the Scanner Delays and Laser Delays, among other things, Amax
of SCANahead system HeadNo is required. The delays are only calculated for this
SCANahead system, but are also used unchanged for the second one. If the two
SCANahead systems differ too much for example, in Amax, unwanted deviations may
occur between the markings.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of version DLL 600, OUT 600.
Last change with version DLL 605: data type of Amax.
References set_scanahead_params,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Mode = 2 )because then they would be scaled again.
Control") it is recommended that the single SCANahead systems
get_last_error
set_scanahead_params was previously
