Micro_Vector_Rel_3D; Move_To - Scanlab RTC6 PCIe Board Installation And Operation Manual

Normal List

micro_vector_rel_3d

Command
Function Moves the output point (of the laser focus) by a
Microsteps) directly from the current position to the specified position (relative coordinate
values) within the
Restriction If the Option "3D"
select_cor_table), then micro_vector_rel_3d has the same effect as micro_vector_rel.
micro_vector_rel_3d( dX, dY, dZ, LasOn, LasOff )
Call
Parameters dX
dY
dZ
LasOn
LasOff
Comments • The coordinates for the micro vector end point are to be supplied as relative
coordinates with respect to the current position. Otherwise, micro_vector_rel_3d is
identical to
• The
RTC4RTC6 New command.
RTC4 Compatibility
RTC5RTC6 Unchanged functionality.
RTC5 Compatibility
Version info Available as of DLL 600, OUT 600, RBF 600.
References micro_vector_abs_3d,
Ctrl Command move_to
Comments • move_to is described in the manual "Installation and Operation RTC Step Motor
Extension for the RTC4 and RTC5 PC interface boards" (available in English only).
• move_to has been introduced for the "RTC4 STEP MOTOR EXTENSION"
extension board (#112097).
• move_to is not supported by "RTC5/6 varioSCAN 40 FLEX Extension" extension board
(#128683). See also
Extension"", page
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
3D Image Field.
is not enabled or no 3D correction table has been assigned (see
Relative x coordinate of the micro vector end point. In bits.
X
Otherwise, like wie
Relative y coordinate of the micro vector end point. In bits.
Y
Otherwise, like wie
Relative z coordinate of the micro vector end point. In bits.
Z
Otherwise, like wie
LasOn
Like from micro_vector_abs_3d.
LasOff
Like from micro_vector_abs_3d.
micro_vector_abs_3d
Microvector is always executed as a
Mode: see micro_vector_abs_3d.
Mode: see micro_vector_abs_3d.
micro_vector_rel
Chapter 2.8.7 "Extension Board "RTC5/6 varioSCAN FLEX
46.
"Hard Jump" (without split-up into
von micro_vector_abs_3d.
von micro_vector_abs_3d.
von micro_vector_abs_3d.
(see comments there).
"Hard Jump".
550
