Ctrl Command get_jump_table
Function Reads out the
1024 corresponding unsigned 16-bit values to the specified PC address.
ErrorCode = get_jump_table( Addr )
Call
Addr
Parameters
Result Error code.
As an unsigned 32-bit value.
0
11
Notes • Do not call get_jump_table during processing of a list.
• The data format is "1024 16-bit values" representing the delay values for a piecewise
linear interpolation at the sampling points (=jump lengths) N × 1024 with 0  N <
1024. The values can thus also be directly generated or modified by users.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
set_jump_table,
Reference
Ctrl Command get_lap_time
Function Returns the current
TimerValue = get_lap_time()
Call
Result RTC6 Timer
As a 64-bit IEEE floating point value.
Comments • get_lap_time serves to query the elapsed time of a time consuming marking during
processing.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References get_time,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Jump Delay table which is currently stored on the board. Then copies the
PC address for the 2048 byte memory area.
No error.
RTC6 board driver error.
load_jump_table_offset
RTC6 Timer value (without resetting it to zero).
value in seconds since the last call of save_and_restart_timer. In seconds.
save_and_restart_timer
411
