Ctrl Command set_standby
Function Defines the output period and the pulse length of the standby pulses for "laser standby"
operation or – in
for Signals for "Laser Active" Operation
set_standby( HalfPeriod, PulseLength )
Call
HalfPeriod
Parameters
PulseLength
• After a hardware reset, (and after load_program_file), the LASER1, LASER2 and
Comments
LASERON ports must be first-time-activated with
pulses can be activated by set_standby or set_standby_list, see
Control", page
set_laser_control.
• The standby pulses are available in all laser modes
YAG Mode 2, YAG Mode 3,
• The standby pulses can be deactivated (turned off) by setting the standby pulse length
and/or the standby output period to zero (default).
• With HalfPeriod, half the standby output period must be specified, see
Figure
• If PulseLength is larger than the output period (2 × HalfPeriod), the laser is
permanently on.
• The laser mode is set with set_laser_mode, see also
page
Control Signals
set_laser_pulses_ctrl,
RTC4RTC6 Basically unchanged functionality. In addition: increased value range.
In RTC4 Compatibility
PulseLength by 8. The allowed value ranges decrease accordingly.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_standby_list,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Laser Mode 4 and
Half of the standby output period.
As an unsigned 32-bit value.
1 bit equals 1/64 µs.
Allowed value range: [0...+(2
Pulse length of the standby pulses.
As an unsigned 32-bit value.
1 bit equals 1/64 µs.
Allowed value range: [0...(2
184. At the same time, the signal level of the standby pulses are set by
Laser Mode
54.
184. To set the active output period and pulse length for the "laser active"
(beside for Laser Mode 4
set_laser_pulses
Mode, the RTC6 multiplies the specified values for HalfPeriod and
get_standby
Laser Mode 6 – the continuously-running laser signals
and "laser standby" operation.
32
–1)].
32
–1)].
set_laser_control
(CO Mode, YAG Mode 1,
2
4, YAG Mode 5, Laser Mode
Chapter 7.4 "Laser Control",
and Laser Mode
or set_laser_timing.
before standby
Chapter 7.4 "Laser
6).
Figure 52 and
Laser
6), are set by
744
