Normal List timed_jump_rel_3d
Command
Function Moves the output point (of the laser focus) for the specified jump duration along a
3D vector from the current position to the specified position (relative coordinate values)
within the
Restriction If the Option "3D"
select_cor_table), then timed_jump_rel_3d has the same effect as timed_jump_rel.
However, split-up into
the effective jump speed in the xy plane.
timed_jump_rel_3d( dX, dY, dZ, T )
Call
dX
Parameters
dY
dZ
T
Comments • The coordinates for the jump vector end point are to be supplied as relative
coordinates with respect to the current position. Otherwise, timed_jump_rel_3d is
identical to
RTC4RTC6 New command.
See jump_rel_3d.
RTC5RTC6 Unchanged functionality. In addition: increased value range.
Version info Available as of DLL 600, OUT 600, RBF 600.
References timed_jump_abs_3d, jump_rel_3d,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
3D Image Field.
is not enabled or no 3D correction table has been assigned (see
Microsteps is calculated like a 3D command and hence influences
Like jump_rel_3d.
Like jump_rel_3d.
Like jump_rel_3d.
Duration of the complete jump vector. In µs.
As a 64-bit IEEE floating point value.
Allowed value range: [0...167,772,160]. The parameter is rounded to an
integer-multiple of 10. Out-of-range values are clipped.
If T < 5, then timed_jump_rel_3d behaves like jump_rel_3d.
timed_jump_abs_3d (see the comments there).
timed_jump_rel
