Scanlab RTC6 PCIe Board Installation And Operation Manual page 497

Ctrl Command load_correction_file
Except its basic function and the parameters Name and No, the functionality of
RTC4RTC6
load_correction_file has substantially changed:
• load_correction_file now uses the new parameter Dim. This allows, for instance,
storage of 3D correction files as 2D correction tables and storage of 2D correction files
as 3D correction tables.
• Now, up to 8 3D correction tables can be stored in RTC6 memory (in the 3D-enabled
version). However, two 3D correction tables can not be simultaneously assigned to the
scan head connector (see select_cor_table).
• The parameters k, Phi and Offset no longer exist. Therefore, table transformations
(scaling, rotation, translation) are no longer possible during loading of the
correction file. Such coordinate transformations can now be specified by set_scale,
set_angle
• select_cor_table
page
• load_correction_file does not return to the user program until the correction motion
has been completed (see comments above).
RTC5RTC6 Changed functionality.
• load_correction_file lets you load 8 correction tables simultaneously into the RTC6
memory.
• Overlaps no longer exist between memory areas used elsewhere.
Version info Available as of DLL 600, OUT 600, RBF 600.
References —
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
and set_offset in addition to set_matrix.
is automatically called, see comments above and
176.
Section "Notes",
497
