Ctrl Command get_marking_info
Function
Returns information about any boundary exceedances during Processing-on-the-fly
correction as well as improper encoder signals.
get_marking_info also returns the error bits of automatic suppression of
Signals.
Call
MarkingInfo = get_marking_info()
Result
Error code. As an unsigned 32-bit value.
Bit #0
(LSB)
Bit #1
Bit #2
Bit #3
Bit #4
Bit #5
Bit #6
Bit #7
Bit #8
Bit #9
Bit #10
Bit #11
Bit #12
Bit #13
Bit #14
Bit #15
Bit #16
Bit #17
Bit #18
Bit #19
Bit #20
Bit #21
Bit #22
Bit #23
Bit #24
Bit #25
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
= 1:
Processing-on-the-fly underflow in x direction (X < –524,288).
= 1:
Processing-on-the-fly overflow in x direction (X > +524,287).
= 1:
Processing-on-the-fly underflow in y direction (Y < –524,288).
= 1:
Processing-on-the-fly overflow in y direction (Y > +524,287).
= 1:
Processing-on-the-fly underflow in x direction (X < Xmin).
= 1:
Processing-on-the-fly overflow in x direction (X > Xmax).
= 1:
Processing-on-the-fly underflow in y direction (Y < Ymin).
= 1:
Processing-on-the-fly overflow in y direction (Y > Ymax).
= 1:
TriggerError: an enabled external trigger or simulated trigger occurred
during execution of a list.
= 1:
An error has occurred during activation of Processing-on-the-fly
correction by activate_fly_2d, activate_fly_2d_encoder,
activate_fly_xy
or
also
Chapter 8.6.7 "Synchronizing Processing-on-the-fly Applications",
page
252,
Chapter 8.6.8 "Encoder Resets", page 254
Chapter 8.6.9 "Monitoring Processing-on-the-fly Corrections",
page
255.
PosAck error bit of scan system A, x axis.
TempOK error bit of scan system A, x axis.
PowerOK error bit of scan system A, x axis.
PosAck error bit of scan system A, y axis.
TempOK error bit of scan system A, y axis.
PowerOK error bit of scan system A, y axis.
= 1:
Signal 1 of encoder input port
= 1:
Signal 2 of encoder input port
= 1:
Signal 1 of encoder input port
= 1:
Signal 2 of encoder input port
= 1:
Improper signal sequence at encoder input port
= 1:
Improper signal sequence at encoder input port
= 1:
Processing-on-the-fly underflow in z direction (Z < –524,288).
= 1:
Processing-on-the-fly overflow in z direction (Z > +524,287).
= 1:
Processing-on-the-fly underflow in z direction (Z < Zmin).
= 1:
Processing-on-the-fly overflow in z direction (Z > Zmax).
activate_fly_xy_encoder
ENCODER X
has too-short spacing.
ENCODER X
has too-short spacing.
ENCODER Y
has too-short spacing.
ENCODER Y
has too-short spacing.
Laser Control
("ActivateFlyError"). See
and
ENCODER
X.
ENCODER
Y.
415
