Table 6:
Output Port Where at the RTC6 PCIe Board
1 12-bit analog output port
1
2 12-bit analog output port
2
3 8-bit digital output port
4 16-bit digital output port
(a)(b)
5 Pulse length
(a) Port = 5 cannot be combined with Mode = 0.
(b) Port = 5 cannot be combined with Mode = 256.
RTC6 boards
Doc. Rev. 1.0.21 en-US
8 Advanced Functions for Scan Head Control and Laser Control
LASER Connector, page 73,
See Figure 17.
LASER Connector, page 73,
See Figure 17.
MARKING ON THE FLY Socket Connector, page
ANALOG OUT2
See Figure 25.
EXTENSION 2 Socket Connector, page 80
See Figure 24.
EXTENSION 1 Socket Connector, page 78
See Figure 22.
LASER Connector, page 73, LASER1
See Figure 17.
ANALOG OUT1
ANALOG OUT2
82,
