Ctrl Command get_values
Function Returns the current values of up to 4 specified signals.
get_values( SignalPtr, ResultPtr )
Call
SignalPtr
Parameters
ResultPtr
Comments • Up to 4 desired signals can be simultaneously queried. The selectable signal types are
identical to those of
range, signal types and other information). The to-be-outputted signal types must be
specified by SignalPtr. The corresponding signal values are then stored by ResultPtr.
For storage of each queried data set, the user program must make available (at the
address specified by ResultPtr) 4 × 4 bytes of PC memory.
• get_values functions similarly to
0 and performs no query on channels for which an invalid signal type has been
specified by SignalPtr. A
generated if all 4 specified signal types are invalid.
• If any of the pointer parameters are NULL, then get_values is not executed and a
get_last_error
RTC4RTC6 New command.
Even in
are transferred to the PC as 32-bit values (see comments for get_value).
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References get_value, set_trigger,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Pointer (in C and C++ data type ULONG_PTR, an unsigned 32-bit value or
unsigned 64-bit value) to an array of 4 unsigned 32-bit values, where the to-
be-outputted signal types are specified.
Pointer (in C and C++ data type ULONG_PTR, an unsigned 32-bit value or
unsigned 64-bit value) to an array of 4 signed 32-bit values, where the current
values of the up to 4 specified signals are to be stored.
set_trigger
get_last_error
return code of
RTC4 Compatibility Mode, the 4 returned values are in the RTC6 20-bit range, but
transform
(refer to the comments there for the allowed value

get_value

(see comments there). get_values returns
RTC6_PARAM_ERROR
return code
RTC6_PARAM_ERROR
is generated.
is only
