Code
Code
HIGH
LOW
(hex)
(hex)
05
2A
Notice! Generic information. May be incomplete or even incorrect for your scan system.
RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
Data type transmitted by the scan system
As of scan system firmware  2001.
Stop event code
Value range with 16-bit protocol: [0...65,535].
Value range with 20-bit protocol: [0...65,535].
16-bit
20-bit
protocol
protocol
(hex)
(hex)
0001
00010
The galvanometer scanner has reached a critical edge
position.
0002
00020
AD converter error.
0003
00030
Temperature in scan system above max. allowed value.
0004
00040
External power supply voltages have dropped below the
allowed value.
0005
00050
Flags are not valid.
0006
00060
Reserved.
...
...
...
000C
000C0
Reserved.
000D
000D0
Reserved.
000E
000E0
Position Acknowledge time out (set position not reached for
long time).
000F
000F0
Reserved.
0014
00140
Reserved.
0015
00150
Reserved.
0016
00160
Reserved.
0017
00170
Reserved.
0018
00180
Reserved.
0019
00190
Reserved.
001A
001A0
Reserved.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
960
