12-Bit Analog Output Ports
As with RTC6 PCIe Boards, see
"LASER Connector", page
pin numbers differ.
Signal RTC6 Ethernet
Board
ANALOG OUT1 Pin (15)
(a)
ANALOG OUT2 Pin (14)
(a) With the RTC6 PCIe Board the ANALOG OUT2 signal is
additionally available at the MARKING ON THE FLY
socket connector.
Input and Output Wiring
The input and output wiring of the 16-pin LASER
socket connector is shown in
to RTC6 PCIe Boards, except the pin numbers.
RTC6 boards
Doc. Rev. 1.0.21 en-US
16 Appendix A: The RTC6 Ethernet Board
Chapter 4.6.1
73. However, note that the
RTC6 PCIe
Board
Pin (08)
Pin (15)
Figure 77. It is identical
Pin 16
Wire
16
15
14
13
12
11
10
09
1 2
08
07
06
05
04
03
02
01
Pin 1 Pin 2
Corresponds functionally to cable #116048 (l=0.2 m).
Legend
1. Connector, 16-pin female. For LASER
socket connector, see Figure
Identical in construction to Würth 61201623021.
2. Flat ribbon cable 26 AWG, 20 conductors,
pitch 1.27 mm.
3. Connector, 15-pin D-SUB, female.
Cable (proposal). Actual implementation may differ
according to customer needs.
The depicted items are not in the standard scope of delivery
of the RTC6 Ethernet Board!
15
16-> x
8
15->08
14->15
13->07
12->14
11->06
10->13
09->05
3
08->12
07->04
06->11
05->03
04->10
03->02
9
02->09
1
01->01
75.
