General-purpose I/Os (GPIO)
MODE(i)
[1:0]
00
11
1. GP = general-purpose, PP = push-pull, PU = pull-up, PD = pull-down, OD = open-drain, AF = alternate
function.
7.3.1

General-purpose I/O (GPIO)

During and just after reset, the alternate functions are not active and most of the I/O ports
are configured in analog mode.
The debug pins are in AF pull-up/pull-down after reset:
•
PA14: SWCLK in pull-down
•
PA13: SWDIO in pull-up
Note: PA14 is shared with BOOT0 functionality. Caution is required as the debugging device can
manipulate BOOT0 pin value.
Upon reset, the UCPD CCx lines present a pull-down resistor that can be disabled by
setting the UCPDx_STROBE bit of the SYSCFG_CFGR1 register.
When the pin is configured as output, the value written to the output data register
(GPIOx_ODR) is output on the I/O pin. It is possible to use the output driver in push-pull
mode or open-drain mode (only the low level is driven, high level is HI-Z).
The input data register (GPIOx_IDR) captures the data present on the I/O pin at every AHB
clock cycle.
All GPIO pins have weak internal pull-up and pull-down resistors, which can be activated or
not depending on the value in the GPIOx_PUPDR register.
7.3.2

I/O pin alternate function multiplexer and mapping

The device I/O pins are connected to on-board peripherals/modules through a multiplexer
that allows only one peripheral alternate function (AF) connected to an I/O pin at a time. In
this way, there can be no conflict between peripherals available on the same I/O pin.
234/1390
Table 42. Port bit configuration table
OSPEED(i)
OTYPE(i)
[1:0]
x x
x x
x x
x x
x x
x x
x x
x x
RM0444 Rev 5
(1)
PUPD(i)
[1:0]
x 0 0
x 0 1
x 1 0
x 1 1
x 0 0
x 0 1
x 1 0
x 1 1
(continued)
I/O configuration
Input Floating
Input PU
Input PD
Reserved (input floating)
Input/output Analog
Reserved
RM0444
