Analog-to-digital converter (ADC)
Bits 8:5 OVSS[3:0]: Oversampling shift
This bit is set and cleared by software.
0000: No shift
0001: Shift 1-bit
0010: Shift 2-bits
0011: Shift 3-bits
0100: Shift 4-bits
0101: Shift 5-bits
0110: Shift 6-bits
0111: Shift 7-bits
1000: Shift 8-bits
Others: Reserved
Note: The software is allowed to write this bit only when ADSTART = 0 (which ensures that no
conversion is ongoing).
Bits 4:2 OVSR[2:0]: Oversampling ratio
This bit filed defines the number of oversampling ratio.
000: 2x
001: 4x
010: 8x
011: 16x
100: 32x
101: 64x
110: 128x
111: 256x
Note: The software is allowed to write this bit only when ADSTART = 0 (which ensures that no
conversion is ongoing).
Bit 1 Reserved, must be kept at reset value.
Bit 0 OVSE: Oversampler Enable
This bit is set and cleared by software.
0: Oversampler disabled
1: Oversampler enabled
Note: Software is allowed to write this bit only when ADSTART = 0 (which ensures that no conversion
is ongoing).
15.12.6

ADC sampling time register (ADC_SMPR)

Address offset: 0x14
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
SMPSE SMPSE SMPSE SMPSE
L7 L6 L5
rw rw rw
392/1390
28 27 26 25
SMPSE SMPSE
Res.
L18 L17
rw rw
12 11 10 9
SMPSE SMPSE SMPSE
L4 L3 L2 L1
rw rw rw rw
24 23 22
SMPSE SMPSE SMPSE SMPSE
L16 L15 L14
rw rw rw
8 7 6
SMPSE
Res. SMP2[2:0]
L0
rw rw
RM0444 Rev 5
21 20 19 18
SMPSE SMPSE SMPSE
L13 L12 L11 L10
rw rw rw rw
5 4 3 2
Res.
rw rw rw
RM0444
17 16
SMPSE SMPSE
L9 L8
rw rw
1 0
SMP1[2:0]
rw rw
