RM0444
Bits 5:2 TSEL1[3:0]: DAC channel1 trigger selection
These bits select the external event used to trigger DAC channel1
0000: SWTRIG1
0001: dac_ch1_trg1
0010: dac_ch1_trg2
...
1111: dac_ch1_trg15
Refer to the trigger selection tables in
details on trigger configuration and mapping.
Note: Only used if bit TEN1 = 1 (DAC channel1 trigger enabled).
Bit 1 TEN1: DAC channel1 trigger enable
This bit is set and cleared by software to enable/disable DAC channel1 trigger.
0: DAC channel1 trigger disabled and data written into the DAC_DHR1 register are
transferred one dac_pclk clock cycle later to the DAC_DOR1 register
1: DAC channel1 trigger enabled and data from the DAC_DHR1 register are transferred
three dac_pclk clock cycles later to the DAC_DOR1 register
Note: When software trigger is selected, the transfer from the DAC_DHR1 register to the
Bit 0 EN1: DAC channel1 enable
This bit is set and cleared by software to enable/disable DAC channel1.
0: DAC channel1 disabled
1: DAC channel1 enabled
16.7.2
DAC software trigger register (DAC_SWTRGR)
Address offset: 0x04
Reset value: 0x0000 0000
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
DAC_DOR1 register takes only one dac_pclk clock cycle.
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
8
Res.
Res.
Res.
Res.
RM0444 Rev 5
Digital-to-analog converter (DAC)
Section 16.4.2: DAC pins and internal signals
23
22
21
20
Res.
Res.
Res.
Res.
7
6
5
4
Res.
Res.
Res.
Res.
for
19
18
17
Res.
Res.
Res.
3
2
1
Res.
Res.
SWTRIG2 SWTRIG1
w
427/1390
16
Res.
0
w
441
