RNG registers

The RNG is associated with a control register, a data register and a status register.
19.7.1

RNG control register (RNG_CR)

Address offset: 0x000
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:6 Reserved, must be kept at reset value.
Bit 5 CED: Clock error detection
Bit 4 Reserved, must be kept at reset value.
Bit 3 IE: Interrupt Enable
Bit 2 RNGEN: True random number generator enable
Bits 1:0 Reserved, must be kept at reset value.
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
0: Clock error detection is enable
1: Clock error detection is disable
The clock error detection cannot be enabled nor disabled on-the-fly when the RNG is
enabled, i.e. to enable or disable CED the RNG must be disabled.
0: RNG Interrupt is disabled
1: RNG Interrupt is enabled. An interrupt is pending as soon as DRDY='1', SEIS='1' or
CEIS=1 in the RNG_SR register.
0: True random number generator is disabled. Analog noise sources are powered off and
logic clocked by the RNG clock is gated.
1: True random number generator is enabled.
True random number generator (RNG)
24
23
22
Res.
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
CED
RM0444 Rev 5
21
20
19
18
Res.
Res.
Res.
5
4
3
2
Res.
IE
RNGEN
rw
rw
rw
17
16
Res.
Res.
1
0
Res.
Res.
469/1390
472
