Low-power timer (LPTIM)
Bits 31:7 Reserved, must be kept at reset value.
Bit 6 DOWNIE: Direction change to down Interrupt Enable
0: DOWN interrupt disabled
1: DOWN interrupt enabled
Note: If the LPTIM does not support encoder mode feature, this bit is reserved. Please refer to
Section 26.3: LPTIM
Bit 5 UPIE: Direction change to UP Interrupt Enable
0: UP interrupt disabled
1: UP interrupt enabled
Note: If the LPTIM does not support encoder mode feature, this bit is reserved. Please refer to
Section 26.3: LPTIM
Bit 4 ARROKIE: Autoreload register update OK Interrupt Enable
0: ARROK interrupt disabled
1: ARROK interrupt enabled
Bit 3 CMPOKIE: Compare register update OK Interrupt Enable
0: CMPOK interrupt disabled
1: CMPOK interrupt enabled
Bit 2 EXTTRIGIE: External trigger valid edge Interrupt Enable
0: EXTTRIG interrupt disabled
1: EXTTRIG interrupt enabled
Bit 1 ARRMIE: Autoreload match Interrupt Enable
0: ARRM interrupt disabled
1: ARRM interrupt enabled
Bit 0 CMPMIE: Compare match Interrupt Enable
0: CMPM interrupt disabled
1: CMPM interrupt enabled
Caution: The LPTIM_IER register must only be modified when the LPTIM is disabled (ENABLE bit reset to '0')
26.7.4

LPTIM configuration register (LPTIM_CFGR)

Address offset: 0x00C
Reset value: 0x0000 0000
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
TRIGSEL[2:0] Res.
rw rw rw
Bits 31:30 Reserved, must be kept at reset value.
Bit 29 Reserved, must be kept at reset value.
Bits 28:25 Reserved, must be kept at reset value.
848/1390
implementation.
implementation.
27 26 25 24
Res. Res. Res. ENC
rw
11 10 9 8
PRESC[2:0] Res.
rw rw rw
RM0444 Rev 5
23 22 21
COUNT
PRELOAD WAVPOL WAVE TIMOUT
MODE
rw rw rw
7 6 5
TRGFLT[1:0] Res.
rw rw
RM0444
20 19 18 17
TRIGEN[1:0]
rw rw rw rw
4 3 2 1
CKFLT[1:0] CKPOL[1:0]
rw rw rw rw
16
Res.
0
CKSEL
rw
