General-purpose timers (TIM2/TIM3/TIM4)
Bit 2 CC2G: Capture/compare 2 generation
Bit 1 CC1G: Capture/compare 1 generation
Bit 0 UG: Update generation
22.4.7

TIMx capture/compare mode register 1 [alternate] (TIMx_CCMR1)

(x = 2 to 4)
Address offset: 0x18
Reset value: 0x0000 0000
The same register can be used for input capture mode (this section) or for output compare
mode (next section). The direction of a channel is defined by configuring the corresponding
CCxS bits. All the other bits of this register have a different function in input and in output
mode.
Input capture mode:
31 30 29
Res. Res. Res. Res.
15 14 13
IC2F[3:0]
rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:12 IC2F[3:0]: Input capture 2 filter
Bits 11:10 IC2PSC[1:0]: Input capture 2 prescaler
680/1390
Refer to CC1G description
This bit is set by software in order to generate an event, it is automatically cleared by
hardware.
0: No action
1: A capture/compare event is generated on channel 1:
If channel CC1 is configured as output:
CC1IF flag is set, Corresponding interrupt or DMA request is sent if enabled.
If channel CC1 is configured as input:
The current value of the counter is captured in TIMx_CCR1 register. The CC1IF flag is set,
the corresponding interrupt or DMA request is sent if enabled. The CC1OF flag is set if the
CC1IF flag was already high.
This bit can be set by software, it is automatically cleared by hardware.
0: No action
1: Re-initialize the counter and generates an update of the registers. Note that the prescaler
counter is cleared too (anyway the prescaler ratio is not affected). The counter is cleared if
the center-aligned mode is selected or if DIR=0 (upcounting), else it takes the auto-reload
value (TIMx_ARR) if DIR=1 (downcounting).
28 27 26 25
Res. Res. Res.
12 11 10 9
IC2PSC[1:0] CC2S[1:0]
rw rw rw rw
24 23 22
Res. Res. Res.
8 7 6
IC1F[3:0]
rw rw rw
RM0444 Rev 5
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
IC1PSC[1:0]
rw rw rw rw
RM0444
17 16
Res. Res.
1 0
CC1S[1:0]
rw rw
