Bits 31:9 Reserved, must be kept at reset value.

Bits 8:0 PCROP2A_END[8:0]: PCROP2A area end offset, Bank 2

Note: Values corresponding to addresses outside the Main memory are not allowed.

WRP2A address option bytes

Flash memory address: 0x1FFF 7848

Reset value: 0x0000 00FF (ST production value)

Bits 31:23 Reserved, must be kept at reset value.

Bits 22:16 WRP2A_END[6:0]: WRP area A end offset, Bank 2

Note: Values corresponding to addresses outside the Main memory are not allowed.

Bits 15:7 Reserved, must be kept at reset value.

Bits 6:0 WRP2A_STRT[6:0]: WRP area A start offset, Bank 2

Note: Values corresponding to addresses outside the Main memory are not allowed.

WRP2B address option bytes

Flash memory address: 0x1FFF 7850

Reset value: 0x0000 00FF (ST production value)

PCROP2A_END contains the offset of the last PCROP subpage of the PCROP2A area in

Bank 2 of dual-bank devices.

WRP2A_END contains the offset of the last page of the WRP area A in Bank 2 of dual-bank

WRP2A_STRT contains the offset of the first page of the WRP area A in BAnk 2 of dual-

bank devices.

RM0444 Rev 5

Embedded Flash memory (FLASH)

WRP2A_END[6:0]

WRP2A_STRT[6:0]

WRP2B_END[6:0]

WRP2B_STRT[6:0]
