Direct memory access controller (DMA)
Bit 17 CTCIF5: transfer complete flag clear for channel 5
Bit 16 CGIF5: global interrupt flag clear for channel 5
Bit 15 CTEIF4: transfer error flag clear for channel 4
Bit 14 CHTIF4: half transfer flag clear for channel 4
Bit 13 CTCIF4: transfer complete flag clear for channel 4
Bit 12 CGIF4: global interrupt flag clear for channel 4
Bit 11 CTEIF3: transfer error flag clear for channel 3
Bit 10 CHTIF3: half transfer flag clear for channel 3
Bit 9 CTCIF3: transfer complete flag clear for channel 3
Bit 8 CGIF3: global interrupt flag clear for channel 3
Bit 7 CTEIF2: transfer error flag clear for channel 2
Bit 6 CHTIF2: half transfer flag clear for channel 2
Bit 5 CTCIF2: transfer complete flag clear for channel 2
Bit 4 CGIF2: global interrupt flag clear for channel 2
Bit 3 CTEIF1: transfer error flag clear for channel 1
Bit 2 CHTIF1: half transfer flag clear for channel 1
Bit 1 CTCIF1: transfer complete flag clear for channel 1
Bit 0 CGIF1: global interrupt flag clear for channel 1
10.6.3

DMA channel x configuration register (DMA_CCRx)

Address offset: 0x08 + 0x14 * (x - 1), (x = 1 to 7)
Reset value: 0x0000 0000
The register fields/bits MEM2MEM, PL[1:0], MSIZE[1:0], PSIZE[1:0], MINC, PINC, and DIR
are read-only when EN = 1.
The states of MEM2MEM and CIRC bits must not be both high at the same time.
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
MEM2
Res. PL[1:0]
MEM
rw rw rw
290/1390
27 26 25 24
Res. Res. Res. Res.
11 10 9 8
MSIZE[1:0] PSIZE[1:0]
rw rw rw rw
RM0444 Rev 5
23 22 21 20
Res. Res. Res. Res.
7 6 5
MINC PINC CIRC DIR
rw rw rw rw
19 18 17
Res. Res. Res.
4 3 2 1
TEIE HTIE TCIE
rw rw rw
RM0444
16
Res.
0
EN
rw
