RM0444
4.4.7
Power status clear register (PWR_SCR)
Address offset: 0x18
Reset value: 0x0000 0000.
Access: three additional APB cycles are needed to write this register, compared to a
standard APB write.
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:9 Reserved, must be kept at reset value.
Bit 8 CSBF: Clear standby flag
Setting this bit clears the SBF flag in the PWR_SR1 register.
Bits 7:6 Reserved, must be kept at reset value.
Bit 5 CWUF6: Clear wakeup flag 6
Setting this bit clears the WUF6 flag in the PWR_SR1 register.
Bit 4 CWUF5: Clear wakeup flag 5
Setting this bit clears the WUF5 flag in the PWR_SR1 register.
Bit 3 CWUF4: Clear wakeup flag 4
Setting this bit clears the WUF4 flag in the PWR_SR1 register.
Bit 2 CWUF3: Clear wakeup flag 3
Setting this bit clears the WUF3 flag in the PWR_SR1 register.
Bit 1 CWUF2: Clear wakeup flag 2
Setting this bit clears the WUF2 flag in the PWR_SR1 register.
Bit 0 CWUF1: Clear wakeup flag 1
Setting this bit clears the WUF1 flag in the PWR_SR1 register.
4.4.8
Power Port A pull-up control register (PWR_PUCRA)
Address offset: 0x20
Reset value: 0x0000 0000. This register is not reset when exiting Standby modes and with
PWRRST bit in the
Access: Additional APB cycles are needed to access this register vs. a standard APB
access (3 for a write and 2 for a read).
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
APB peripheral reset register 1
24
23
22
Res.
Res.
Res.
8
7
6
CWUF
CSBF
Res.
Res.
w
(RCC_APBRSTR1).
RM0444 Rev 5
Power control (PWR)
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
CWUF
CWUF
CWUF
6
5
4
3
w
w
w
w
17
16
Res.
Res.
1
0
CWUF
CWUF
2
1
w
w
151/1390
159
